- Sophisticated class-A design and specially-selected high-grade FETs for a signal boost without coloration
- Vastly lower output impedance and nearly half the noise of anything else on the market to raise any mic level with clarity
- Always a consistent +28dB regardless of the connected load to enable mics with a lower output
- Provides improved level to a preamp – all without adding noise or coloration, bringing new life to your favorite passive microphones
- All-metal housing and premium finish ensures the DM1 can handle demanding on-tour or recording/broadcast studio lifestyles
- Gold plated XLR connector for loss-free reliable signal connection
- Perfect for podcasting, recording, or live sound
Power
- Electrical Impedance135 Ohms
- Recommended Load Impedance>1K Ohms
- Connectivity3-pin male/female XLR connector
- Powering48V Phantom Power (P48 according to IEC 61938)
Sound
- Frequency range10 Hz – 120 kHz (-0.3 dB)
- Gain28 dB
- Current consumption3.0 mA
- Max output level (0.5% THD)8.3 dBV (2.6 V)
- Output noise level9 µV (a-weighted)
Dimensions
- Preamp diameter 19 mm (0.75 in.)
- Preamp length 96 mm (3.78 in.)
- Preamp weight 96 mm (3.78 in.)
What’s in the box
- DM1
- sE Logo Sticker
- User manual with warranty card
