Warranty: 3 Years
Behringer P24 Hub Stageconnect Hub
- Distribution hub with StageConnect bus powering for up to 8 personal monitoring mixers
- Compatible with Behringer P24 personal mixers, AES50, Ultranet and Analog Connectivity
- 4 StageConnect front ports for powering 2 daisy-chained mixers each, minimizing on-stage cabling
- 16 balanced analog outputs on 1/4″ TRS, for sending up to 8 personal stereo mixes to wireless IEM transmitters
- StageConnect 26 x 6-channel audio transmission at sub-milisecond latency, 24-Bit uncompressed PCM, 44.1/48 kHz, using a standard XLR cable (DMX cable recommended)
- StageTalk intercom system for communication between FOH, stage technician and musicians
- Stable operation range up to 40 m via DMX type XLR cable – standard microphone cable can be used for short connections
- AES50 In and Thru, with 48 x 48 channels on CAT5E STP cable up to 80 m
- Ultranet Input with 16 channels on CAT5 STP cable up to 75 m
- Ultranet In and Outputs for interfacing with various Behringer P16 personal monitoring equipment
- Integrated sample rate conversion for compatibility with 96 kHz AES50-equipped devices, such as Midas HD consoles
- Rugged 1U rackmount chassis for durability in portable applications
- Integrated auto-ranging switch-mode power supply
